Product Description

1, The pressure vessel is assembled with agitator, the ports for nozzles are customized.

2, The jacket of the vessel is for heating purpose.

3, The electric bars will insert to the nozzels at the bottom of the equipment and heating the thermal oil inside the jacket.

4, The material of vessel contact to medium is made from cladding plate stainless steel s316L and carbon steel Q345R.

5, The material of jacket is Q345R.

6, It is using magnetic shaft sleeve for sealing.

Tank cover nozzle ports

-Tank inner temp measuring port
-Pressure gauge/ Safety valve ports
-Jacket steam circulation inlet/outlet
-Manhole
-Vent port

-Gas inlet port
-Liquid inlet port

Note: all nozzle ports & fitting type can be customized

Magnetic sealed stirrer coupler

-Core technology: Static sealed,magnetic transmission

 -100% ZERO leakage

-Coupler inner with cooling system, avoid coupler inner overheating
