Product Description

Definition of Pressure Vessel Heads

Pressure vessel heads are crucial components of a pressure vessel, serving as the end closures for its cylindrical shell. These heads help maintain the integrity of the vessel by containing internal pressure. Various names are commonly used for these components, including Dish Ends, Formed Heads, End Closures, End Caps, Vessel Ends, and Vessel Caps. However, the most widely recognized term is "Dish Ends."

Types of Pressure Vessel Heads

There are four primary types of pressure vessel heads commonly used in fabrication:

1. Flat Heads

2. Ellipsoidal Heads

3. Torispherical Heads (Flange and Dished Heads)

4. Hemispherical Heads

Flat Heads

Flat heads are the simplest type of pressure vessel heads, but they are less frequently used due to their lower ability to withstand pressure. Since they have a reduced radial section for pressure distribution, the flat surface bears the majority of the stress, making them less economical for high-pressure applications.

Key Terms in Flat Heads:

• Flat Head Inside Diameter (ID)

• Knuckle Radius (R)

• Dish End Total Height (H)

• Straight Face (SF)

Ellipsoidal Heads

Ellipsoidal heads are the most commonly used pressure vessel heads. Their wider radial section allows for better pressure distribution, making them more capable of handling high pressures compared to other types. These heads are highly preferred due to their efficiency and cost-effectiveness. Typically, a 2:1 ellipsoidal head configuration is used, meaning the major axis is twice the length of the minor axis.

Key Terms in 2:1 Ellipsoidal Heads:

• Inside Diameter (ID)

• Crown Radius (C.R)

• Knuckle Radius (K.R)

• Dish End Total Height (H)

• Straight Face (SF)

Torispherical Heads (Flange and Dished Heads)

Torispherical heads are another widely used type of pressure vessel head. They offer good pressure distribution, though slightly lower than ellipsoidal heads. One advantage of torispherical heads is their reduced forming time compared to ellipsoidal heads, making them a popular choice for fabrication.

For the same design conditions, the thickness of torispherical heads is approximately 1.77 times the thickness of the shell for equal design pressure and temperature.

Key Terms in Torispherical Heads:

• Inside Diameter (ID)

• Crown Radius (C.R)

• Knuckle Radius (K.R)

• Dish End Total Height (H)

• Straight Face (SF)

Hemispherical Heads

Hemispherical heads provide the maximum available radial section, which results in superior pressure distribution. Due to this, for the same design conditions, the required thickness of a hemispherical head is roughly half the thickness of the shell for an equivalent pressure and temperature.

Though they are the most economical in terms of material usage, they require the most time for forming.

Key Terms in Hemispherical Heads:

• Inside Diameter (ID)

• Crown Radius (R)

• Dish End Total Height (H)

• Straight Face (SF)

Conclusion

These four primary types of pressure vessel heads are widely used in the fabrication of pressure vessels. The selection of a particular type depends on design conditions, pressure requirements, and manufacturing feasibility. Various calculations, including dish end dimensions, blank diameter, weight, surface area, and volume, are essential for fabrication. Proper selection and design ensure safety, efficiency, and cost-effectiveness in pressure vessel manufacturing.

Production Process of Heads:

Haipei Industry Produce Hot Pressed And Cold Pressed Dished Ends

Picking steel---Cutting---Welding---Heating---Spinning---Stamping---Trimming---Defect detection---QC---Warehousing---Transporttation

Company Information

Haipei Industry is a specialized manufacturer of tank head. With over 30 years of engineered driven expertise ,it is a recognized leader within the tank head industry in china.With unique head forming, fabrication and heat treating capabilities, we offer a diversified range of products. Head diameters is from 3.5" to 393.7'', and Head thickness is from 0.078" to 11.8''. Pressure vessel heads and tank ends are available in a broad range of sizes, shapes, thicknesses and material specifications.

The main products of the company are: shell plate, elliptical head,torispherical heads,spherical dished heads, flat heads, spherical head, expansion joint, corrugated furnace and non-standard parts, and all kinds of stock heads are available for customers. The products are sold to more than 20 provinces and cities and regions in China and exported to foreign countries.

Advantages

 ♦ Small order advantage, flexibly in dealing with orders;

♦ Quality: Strict control of raw materials and the production process;

♦ Advanced technology,best quality,customer satisfaction,reputation first,good after-service;

♦No cracks , delamination, inclusion ,and other defects;

Our Services

1.No cracks,delamination, inclusion ,and other defects;

2.The warranty time is 6 months,except the wearing parts;

3.We provide the best service based on professional and sincerely attitude.
